Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate

Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate
Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate

Large Image :  Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate

Product Details:
Place of Origin: Chengdu, China
Brand Name: PICOUNI
Model Number: AB-888
Payment & Shipping Terms:
Price: $1500
Delivery Time: 8-10 working days
Payment Terms: T/T,L/C,D/A,D/P,Western Union,MoneyGram
Contact Now Chat Now

Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate

Description
Sample Capacity: 8-well Or 16-well (single-row Layout) Fluorescence Channels: 2 Channels (FAM, VIC)
Device Weight: \le 4\text{kg} Ramping Rate: Max. 8^\circ\text{C/sec}
Display & Control: 7-inch Touchscreen

Real-Time PCR System - OEM/ODM Core Specifications
1. General Specifications
  • Sample Capacity: 8-well or 16-well (single-row layout)
  • Fluorescence Channels: 2 channels (FAM, VIC)
  • Device Weight: ≤ 4kg
  • Dimensions: Compact; fits into a standard carry-on suitcase (when combined with extraction unit)
  • Casing Features: Waterproof, anti-corrosion, and wear-resistant
  • Structural Design: Built-in buffer structure to ensure transport safety
  • Customization: Supports case color customization and customer Logo printing.
  • Maintenance Design: Highly modular. Core components such as the thermal block, screen, and optical excitation module can be replaced independently, facilitating easy local service and rapid repair overseas.
2. Performance Parameters
  • Ramping Rate: Max. 8°C/sec
  • Temperature Uniformity: Inter-well temperature CV < 0.2%
  • Lid Design: Electromagnetic auto-locking lid, ensures a complete seal during operation
  • Optical System:
    • High sensitivity, high signal-to-noise ratio (SNR), stable detection of low-copy templates
    • Anti-crosstalk between FAM/VIC channels
  • Power Supply:
    • Supports AC power supply
    • Supports DC power supply (e.g., 12V vehicle-mounted power)
3. Software & Data
  • Display & Control: 7-inch touchscreen
  • User-Friendly Operation:
    • Core detection functions accessible within 3 clicks
    • Real-time display of run status, remaining time, and temperature
    • Real-time display of amplification curves for FAM and VIC channels
  • Program Management:
    • Built-in standard program templates (DNA, RNA, etc.)
    • Supports user-created and fine-tuned programs
  • Baseline/Threshold: Supports automatic and manual adjustment
  • Data Connectivity:
    • USB Port: Supports export of run logs and test reports via USB drive
    • WiFi Function: Built-in WiFi module, supports automatic data transfer to a server (facilitates remote diagnostics)
  • Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate 0

Fast and Accurate Nucleic Acid PCR System with Max. 8 circ ext C/sec Ramping Rate 1
